HY-KG100Full-automatic Enema Glycerini Filling Machine ??

Brief introduction of Enema Glycerini HY-KG100 filling machine
Enema Glycerini HY-KG100 automatic filling machine is our company according to the relevant experience at home and abroad the latest research into products, the product is controlled by computer program, the main parameters of all digital display. Adopting the original preset precision control device, the measuring accuracy is increased by more than twice as compared with the similar type. The computer control part adopts the block inserting design, and the maintenance and replacement is very simple. All the working speed of the cylinder can be adjusted, so that the work is more stable and reliable. The machine can be equipped with two different structure of filling head, in order to meet the filling requirements of different materials. The universal filling head is suitable for filling liquid and flowing paste material. The unique breaking mechanism of the device effectively solves the dripping, makes the filling process more clean, fully meet the requirements of GMP.
This machine is suitable for Enema Glycerini 10-45ml series plastic bottle filling machine is widely used in the pharmaceutical industry. Using the disk positioning filling, electromagnetic oscillation or pneumatic positioning to cover, and then into the sealing work, and production equipment before and after the production line. The design capacity of the equipment is 60-100 bottles / min. the stepless speed regulation of the main engine is achieved. The body is equipped with casters, the bottle machine can be quickly split combined linkage control with the host machine, the production speed matches each other.

The main technical parameters of HY-KG100 Enema Glycerini filling machine

型号/Model： HY-KSL100

灌装头数/Filing head number： 6

加塞头数/Adding plug head： 2

旋盖头数/Capping head number 2

灌装量/Filling volume： 10-30ml

生产能力/Capacity： 60-100 bottles/min

灌装精度/Filling accuracy： ≤ ±1%

合格率/Pass rate： ≥ 98%

电源/Power supply： AC220V 50

总功率/Total power: 3.0 KW

净重/Net weight： About 500kg

外形尺寸/Overall dimension L1400× W1700× H1650mm
